Belden Solutions

Belden Solutions, formerly known as OTN Systems, specializes in high-quality network solutions for a wide range of industrial sectors. These solutions enable high-speed industrial networks with throughput of up to 40 Gbit/s and guaranteed bandwidth allocation for all services — making this technology essential for building transport infrastructure at facilities with strict safety and reliability requirements, where failure can have fatal consequences not only for the business but also for employee lives.

Belden Solutions

KEY EQUIPMENT FEATURES

  • Rugged industrial design
  • Fanless, noiseless cooling
  • Extended temperature range from −20 to +65°C
  • Multiple power supply options (18-60 VDC / 88-300 VDC / 90-264 VAC)
  • Modular design, high switching capacity — 64 Gbit/s
  • Wide variety of interface cards: 1GE with PoE+, 10 GE, E1/T1, 2W/4W E&M, X.21 / V.35, RS232,422,485, C37.94 teleprotection, SDH/SONET, SHDSL
  • Ability to connect various services via fiber or microwave radio over GE
  • Advanced network management via the management system
KEY EQUIPMENT FEATURES

Equipment

XTD-2110-A

XTD-2110-A

  • 10 Ethernet ports
  • 2 serial ports
  • Redundant power supply
  • DIN-rail mounting
  • VRF and VFI functionality
XTR-2124-A(F)

XTR-2124-A(F)

  • 24 Ethernet ports
  • 2 serial ports
  • Redundant power supply
  • VRF and VFI functionality
XT-1104-A

XT-1104-A

  • 4-slot chassis
XT-2206-A

XT-2206-A

  • 6-slot chassis
  • Redundant power supply
  • Redundant central processor
XT-2209-A

XT-2209-A

  • 9-slot chassis
  • Dual slot for L3 board
  • Redundant power supply
  • Redundant central processor
XT-2210-A

XT-2210-A

  • 10-slot chassis
  • Redundant power supply
  • Redundant central processor
XT-2215-A

XT-2215-A

  • 15-slot chassis
  • 1-40 G
  • Redundant power supply
  • Redundant central processor
CSM310-A

CSM310-A

  • 15-slot chassis
  • 1-40 G
  • Redundant power supply
  • Redundant central processor
CSM540-A

CSM540-A

  • Central processor
  • Core level
  • Automatic protection
  • TXCare connector
1-10G-LW

1-10G-LW

  • Interface board
  • Ports: 1 x 10 G optics LAN/WAN
1-40G-LW

1-40G-LW

  • Interface board
  • Ports: 1 x 40 G optics LAN/WAN
4-10G-LW

4-10G-LW

  • Interface board
  • Ports: 4 x 10 G optics LAN/WAN
4-DSL-LW

4-DSL-LW

  • Interface board
  • Ports: 4 x SHDSL
4-GC-LW (PoE)

4-GC-LW (PoE)

  • Interface board
  • Ports: 4x 1000base-T
  • 1x SFP 1000 base-X LAN/WAN
  • Power over Ethernet (PoE)
4-GC-LW

4-GC-LW

  • Interface board
  • Ports: 4x 1000base-T
  • 1x SFP 1000 base-X LAN/WAN
4-GO-LW

4-GO-LW

  • Interface board
  • Ports: 4x 1000 base-X LAN/WAN
  • Smart SFP
16-GEP-L

16-GEP-L

  • Interface board
  • Ports: 16 x1000Base-T
  • Power over Ethernet (PoE)
6-GE-L

6-GE-L

  • Interface board
  • Ports: 6 x1000base-T LAN Layer 2
6-GEP-L

6-GEP-L

  • Interface board
  • Ports: 6 x1000base-T LAN Layer 2
  • Power over Ethernet (PoE)
9-L3A-L

9-L3A-L

  • Interface board
  • Ports: 8x 1G + 1x 10G LAN Layer 3 (primary)
9-L3EA-L

9-L3EA-L

  • Interface board
  • Ports: 8x 1G + 1x 10G LAN Layer 3 (expansion)
4-E1-L

4-E1-L

  • Interface board
  • Ports: E1 x4
  • Technologies: Hitless switching, SyncE
16-E1-L

16-E1-L

  • Interface board
  • Ports: E1 x16
  • Technologies: Hitless switching, SyncE
32-E1-L

32-E1-L

  • Interface board
  • Ports: E1 x32
  • Technologies: Hitless switching, SyncE
4-2/4WEM

4-2/4WEM

  • Interface board
  • Ports: 4 xE&M
4-C37.94

4-C37.94

  • Interface board
  • Ports: 4 xC37.94
6-SERIAL

6-SERIAL

  • Interface board
  • Ports: 6 RS422/RS422/RS485 + server port
7-SERIAL

7-SERIAL

  • Interface board
  • Ports: 7 RS422/RS422/RS485 X.21/V.35
Download OTN SERVICE profile. PDF, 0.1Mb
